Automatic Transfer Switch, 63A 110V/220V Dual Power Selector for Generator & Backup Inverter, L1 Priority, DIN Rail Mount,ATS Adjustable Emergency Power Switch with Guide Rail(110V and 220V Available)
Product details
| Management number | 210751625 | Release Date | 2026/04/02 | List Price | $15.20 | Model Number | 210751625 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Intelligent Automatic Switching: It is compatible with 110V and 220V. This automatic transfer switch detects undervoltage, overvoltage, or overcurrent in the primary power source (L1) and automatically switches to backup power (L2). It reverts to L1 once faults are cleared, with flexible L1/L2 priority settings to suit your needs.
- Adjustable Parameters for Customization: Users can easily modify overcurrent value, startup delay, transfer delay, and priority phase (L1/L2) via buttons. Simply hold the "SET" button to save settings, ensuring compatibility with diverse loads and applications.
- Safety-Enhanced Construction: Made from high-quality PA6 material with V-0 flame retardant rating, it offers superior insulation, high-temperature resistance, and corrosion protection. Prevents electrical faults and short circuits for safe, long-term operation.
- LED Real-Time Monitoring: The built-in LED screen displays operating voltage and current, while indicators show status (overvoltage, undervoltage, main/backup circuit activity). Enables easy fault detection and ensures reliable performance.
- Versatile & Easy Installation: Compact design with standard interfaces and included installation rail allows hassle-free setup—even for non-professionals. Ideal for commercial/industrial facilities, hospitals, data centers, and telecommunications hubs needing stable power.
| Color | White |
|---|---|
| Model | Ats-63a-1518 |
| Wattage | 6930 watts |
| Terminal | Screw |
| Brand Name | Elecbee |
| Unit Count | 1.0 Count |
| Switch Type | Automatic Transfer Switch |
| Circuit Type | Single Phase |
| Contact Type | Din Rail Mount |
| Manufacturer | Elecbee |
| Actuator Type | Automatic |
| Material Type | Metal, Plastic |
| Mounting Type | DIN Rail Mount |
| Connector Type | L1 Terminal |
| Control Method | Push Button |
| Current Rating | 63 Amps |
| Operation Mode | Automatic Transfer |
| Controller Type | Automatic Transfer Switch |
| Item Dimensions | 3.5 x 2.6 x 3.7 inches |
| Number of Items | 1 |
| Contact Material | Copper Alloy |
| Operating Voltage | 110 Volts |
| Specification Met | 50/60hz, CE |
| Included Components | Automatic Transfer Switch, Din Rail Mount, Installation Guide |
| Number of Positions | 2 |
| Connectivity Protocol | Din Rail |
| Insulation Resistance | 500 Megaohms |
| Upper Temperature Rating | 140 Degrees Celsius |
| International Protection Rating | Ip20 |
